FJ400A

The FJ400A Terminal Block is an ultra heavy-duty DIN rail connector designed for high-power distribution systems. Rated up to 400A, it delivers exceptional conductivity, secure cable clamping, and maximum reliability for demanding industrial and large-scale installations.

The Bloxconnect distribution terminal block is designed as a practical and efficient replacement for traditional busbars.

🔹 Advantages

• Highly secure connection
• Space-saving design
• Time-efficient installation

🔹 Type: FJ400A

🔹 Electrical Data

• Max Load: 1000V / 400A (IEC 60947-7-1 Standard)

🔹 Input

• 1 hole, Ø 19 mm (Cable 95 ~ 185 mm²)

🔹 Output

• 2 holes, Ø 9 mm (Cable 6 ~ 35 mm²)
• 5 holes, Ø 6.8 mm (Cable 2.5 ~ 16 mm²)
• 4 holes, Ø 6.1 mm (Cable 2.5 ~ 10 mm²)
